HIMEL Product
Артикулы: HDB3WLE1251C100, HDB3WLE1251C125, HDB3WLE1251C63, HDB3WLE1251C80, HDB3WLE1251D100
Final Distribution > 3 Series RCBO
Цена
Цена по запросу
Уточним стоимость в коммерческом предложении.
- SKU
- 128
- Фото
- 7
- Документы
- 0
- В наличии
- 0
SKU и артикулы
128 позиций
| SKU | Артикулы | Модификация | Наличие | Цена | КП |
|---|---|---|---|---|---|
| HDB3WLE1251C100 |
Производитель: HDB3WLE1251C100
Поставщик: HDB3WLE1251C100
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - C - 100A | Под заказ | По запросу | |
| HDB3WLE1251C125 |
Производитель: HDB3WLE1251C125
Поставщик: HDB3WLE1251C125
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - C - 125A | Под заказ | По запросу | |
| HDB3WLE1251C63 |
Производитель: HDB3WLE1251C63
Поставщик: HDB3WLE1251C63
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - C - 63A | Под заказ | По запросу | |
| HDB3WLE1251C80 |
Производитель: HDB3WLE1251C80
Поставщик: HDB3WLE1251C80
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - C - 80A | Под заказ | По запросу | |
| HDB3WLE1251D100 |
Производитель: HDB3WLE1251D100
Поставщик: HDB3WLE1251D100
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 100A | Под заказ | По запросу | |
| HDB3WLE1251D100G |
Производитель: HDB3WLE1251D100G
Поставщик: HDB3WLE1251D100G
|
Residual Current Operated Circuit Breaker HDB3wLE-125 1P+N D 100A Over-voltage | Под заказ | По запросу | |
| HDB3WLE1251D100Q |
Производитель: HDB3WLE1251D100Q
Поставщик: HDB3WLE1251D100Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 100A - 75mA | Под заказ | По запросу | |
| HDB3WLE1251D100T |
Производитель: HDB3WLE1251D100T
Поставщик: HDB3WLE1251D100T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 100A - 300mA | Под заказ | По запросу | |
| HDB3WLE1251D100W |
Производитель: HDB3WLE1251D100W
Поставщик: HDB3WLE1251D100W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 100A - 50mA | Под заказ | По запросу | |
| HDB3WLE1251D100Y |
Производитель: HDB3WLE1251D100Y
Поставщик: HDB3WLE1251D100Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 100A - 100mA | Под заказ | По запросу | |
| HDB3WLE1251D125 |
Производитель: HDB3WLE1251D125
Поставщик: HDB3WLE1251D125
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 125A | Под заказ | По запросу | |
| HDB3WLE1251D125G |
Производитель: HDB3WLE1251D125G
Поставщик: HDB3WLE1251D125G
|
Residual Current Operated Circuit Breaker HDB3wLE-125 1P+N D 125A Over-voltage | Под заказ | По запросу | |
| HDB3WLE1251D125Q |
Производитель: HDB3WLE1251D125Q
Поставщик: HDB3WLE1251D125Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 125A - 75mA | Под заказ | По запросу | |
| HDB3WLE1251D125T |
Производитель: HDB3WLE1251D125T
Поставщик: HDB3WLE1251D125T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 125A - 300mA | Под заказ | По запросу | |
| HDB3WLE1251D125W |
Производитель: HDB3WLE1251D125W
Поставщик: HDB3WLE1251D125W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 125A - 50mA | Под заказ | По запросу | |
| HDB3WLE1251D125Y |
Производитель: HDB3WLE1251D125Y
Поставщик: HDB3WLE1251D125Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 125A - 100mA | Под заказ | По запросу | |
| HDB3WLE1251D63 |
Производитель: HDB3WLE1251D63
Поставщик: HDB3WLE1251D63
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 63A | Под заказ | По запросу | |
| HDB3WLE1251D63G |
Производитель: HDB3WLE1251D63G
Поставщик: HDB3WLE1251D63G
|
Residual Current Operated Circuit Breaker HDB3wLE-125 1P+N D 63A Over-voltage | Под заказ | По запросу | |
| HDB3WLE1251D63Q |
Производитель: HDB3WLE1251D63Q
Поставщик: HDB3WLE1251D63Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 63A - 75mA | Под заказ | По запросу | |
| HDB3WLE1251D63T |
Производитель: HDB3WLE1251D63T
Поставщик: HDB3WLE1251D63T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 63A - 300mA | Под заказ | По запросу | |
| HDB3WLE1251D63W |
Производитель: HDB3WLE1251D63W
Поставщик: HDB3WLE1251D63W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 63A - 50mA | Под заказ | По запросу | |
| HDB3WLE1251D63Y |
Производитель: HDB3WLE1251D63Y
Поставщик: HDB3WLE1251D63Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 63A - 100mA | Под заказ | По запросу | |
| HDB3WLE1251D80 |
Производитель: HDB3WLE1251D80
Поставщик: HDB3WLE1251D80
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 80A | Под заказ | По запросу | |
| HDB3WLE1251D80G |
Производитель: HDB3WLE1251D80G
Поставщик: HDB3WLE1251D80G
|
Residual Current Operated Circuit Breaker HDB3wLE-125 1P+N D 80A Over-voltage | Под заказ | По запросу | |
| HDB3WLE1251D80Q |
Производитель: HDB3WLE1251D80Q
Поставщик: HDB3WLE1251D80Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 80A - 75mA | Под заказ | По запросу | |
| HDB3WLE1251D80T |
Производитель: HDB3WLE1251D80T
Поставщик: HDB3WLE1251D80T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 80A - 300mA | Под заказ | По запросу | |
| HDB3WLE1251D80W |
Производитель: HDB3WLE1251D80W
Поставщик: HDB3WLE1251D80W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 80A - 50mA | Под заказ | По запросу | |
| HDB3WLE1251D80Y |
Производитель: HDB3WLE1251D80Y
Поставщик: HDB3WLE1251D80Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 1P+N - D - 80A - 100mA | Под заказ | По запросу | |
| HDB3WLE1252C100 |
Производитель: HDB3WLE1252C100
Поставщик: HDB3WLE1252C100
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - C - 100A | Под заказ | По запросу | |
| HDB3WLE1252C125 |
Производитель: HDB3WLE1252C125
Поставщик: HDB3WLE1252C125
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - C - 125A | Под заказ | По запросу | |
| HDB3WLE1252C63 |
Производитель: HDB3WLE1252C63
Поставщик: HDB3WLE1252C63
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - C - 63A | Под заказ | По запросу | |
| HDB3WLE1252C80 |
Производитель: HDB3WLE1252C80
Поставщик: HDB3WLE1252C80
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - C - 80A | Под заказ | По запросу | |
| HDB3WLE1252D100 |
Производитель: HDB3WLE1252D100
Поставщик: HDB3WLE1252D100
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 100A | Под заказ | По запросу | |
| HDB3WLE1252D100G |
Производитель: HDB3WLE1252D100G
Поставщик: HDB3WLE1252D100G
|
Residual Current Operated Circuit Breaker HDB3wLE-125 2P D 100A Over-voltage | Под заказ | По запросу | |
| HDB3WLE1252D100Q |
Производитель: HDB3WLE1252D100Q
Поставщик: HDB3WLE1252D100Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 100A - 75mA | Под заказ | По запросу | |
| HDB3WLE1252D100T |
Производитель: HDB3WLE1252D100T
Поставщик: HDB3WLE1252D100T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 100A - 300mA | Под заказ | По запросу | |
| HDB3WLE1252D100W |
Производитель: HDB3WLE1252D100W
Поставщик: HDB3WLE1252D100W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 100A - 50mA | Под заказ | По запросу | |
| HDB3WLE1252D100Y |
Производитель: HDB3WLE1252D100Y
Поставщик: HDB3WLE1252D100Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 100A - 100mA | Под заказ | По запросу | |
| HDB3WLE1252D125 |
Производитель: HDB3WLE1252D125
Поставщик: HDB3WLE1252D125
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 125A | Под заказ | По запросу | |
| HDB3WLE1252D125G |
Производитель: HDB3WLE1252D125G
Поставщик: HDB3WLE1252D125G
|
Residual Current Operated Circuit Breaker HDB3wLE-125 2P D 125A Over-voltage | Под заказ | По запросу | |
| HDB3WLE1252D125Q |
Производитель: HDB3WLE1252D125Q
Поставщик: HDB3WLE1252D125Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 125A - 75mA | Под заказ | По запросу | |
| HDB3WLE1252D125T |
Производитель: HDB3WLE1252D125T
Поставщик: HDB3WLE1252D125T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 125A - 300mA | Под заказ | По запросу | |
| HDB3WLE1252D125W |
Производитель: HDB3WLE1252D125W
Поставщик: HDB3WLE1252D125W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 125A - 50mA | Под заказ | По запросу | |
| HDB3WLE1252D125Y |
Производитель: HDB3WLE1252D125Y
Поставщик: HDB3WLE1252D125Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 125A - 100mA | Под заказ | По запросу | |
| HDB3WLE1252D63 |
Производитель: HDB3WLE1252D63
Поставщик: HDB3WLE1252D63
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 63A | Под заказ | По запросу | |
| HDB3WLE1252D63G |
Производитель: HDB3WLE1252D63G
Поставщик: HDB3WLE1252D63G
|
Residual Current Operated Circuit Breaker HDB3wLE-125 2P D 63A Over-voltage | Под заказ | По запросу | |
| HDB3WLE1252D63Q |
Производитель: HDB3WLE1252D63Q
Поставщик: HDB3WLE1252D63Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 63A - 75mA | Под заказ | По запросу | |
| HDB3WLE1252D63T |
Производитель: HDB3WLE1252D63T
Поставщик: HDB3WLE1252D63T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 63A - 300mA | Под заказ | По запросу | |
| HDB3WLE1252D63W |
Производитель: HDB3WLE1252D63W
Поставщик: HDB3WLE1252D63W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 63A - 50mA | Под заказ | По запросу | |
| HDB3WLE1252D63Y |
Производитель: HDB3WLE1252D63Y
Поставщик: HDB3WLE1252D63Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 63A - 100mA | Под заказ | По запросу | |
| HDB3WLE1252D80 |
Производитель: HDB3WLE1252D80
Поставщик: HDB3WLE1252D80
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 80A | Под заказ | По запросу | |
| HDB3WLE1252D80G |
Производитель: HDB3WLE1252D80G
Поставщик: HDB3WLE1252D80G
|
Residual Current Operated Circuit Breaker HDB3wLE-125 2P D 80A Over-voltage | Под заказ | По запросу | |
| HDB3WLE1252D80Q |
Производитель: HDB3WLE1252D80Q
Поставщик: HDB3WLE1252D80Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 80A - 75mA | Под заказ | По запросу | |
| HDB3WLE1252D80T |
Производитель: HDB3WLE1252D80T
Поставщик: HDB3WLE1252D80T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 80A - 300mA | Под заказ | По запросу | |
| HDB3WLE1252D80W |
Производитель: HDB3WLE1252D80W
Поставщик: HDB3WLE1252D80W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 80A - 50mA | Под заказ | По запросу | |
| HDB3WLE1252D80Y |
Производитель: HDB3WLE1252D80Y
Поставщик: HDB3WLE1252D80Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 2P - D - 80A - 100mA | Под заказ | По запросу | |
| HDB3WLE1253C100 |
Производитель: HDB3WLE1253C100
Поставщик: HDB3WLE1253C100
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - C - 100A | Под заказ | По запросу | |
| HDB3WLE1253C125 |
Производитель: HDB3WLE1253C125
Поставщик: HDB3WLE1253C125
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - C - 125A | Под заказ | По запросу | |
| HDB3WLE1253C63 |
Производитель: HDB3WLE1253C63
Поставщик: HDB3WLE1253C63
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - C - 63A | Под заказ | По запросу | |
| HDB3WLE1253C80 |
Производитель: HDB3WLE1253C80
Поставщик: HDB3WLE1253C80
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - C - 80A | Под заказ | По запросу | |
| HDB3WLE1253D100 |
Производитель: HDB3WLE1253D100
Поставщик: HDB3WLE1253D100
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 100A | Под заказ | По запросу | |
| HDB3WLE1253D100Q |
Производитель: HDB3WLE1253D100Q
Поставщик: HDB3WLE1253D100Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 100A - 75mA | Под заказ | По запросу | |
| HDB3WLE1253D100T |
Производитель: HDB3WLE1253D100T
Поставщик: HDB3WLE1253D100T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 100A - 300mA | Под заказ | По запросу | |
| HDB3WLE1253D100W |
Производитель: HDB3WLE1253D100W
Поставщик: HDB3WLE1253D100W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 100A - 50mA | Под заказ | По запросу | |
| HDB3WLE1253D100Y |
Производитель: HDB3WLE1253D100Y
Поставщик: HDB3WLE1253D100Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 100A - 100mA | Под заказ | По запросу | |
| HDB3WLE1253D125 |
Производитель: HDB3WLE1253D125
Поставщик: HDB3WLE1253D125
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 125A | Под заказ | По запросу | |
| HDB3WLE1253D125Q |
Производитель: HDB3WLE1253D125Q
Поставщик: HDB3WLE1253D125Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 125A - 75mA | Под заказ | По запросу | |
| HDB3WLE1253D125T |
Производитель: HDB3WLE1253D125T
Поставщик: HDB3WLE1253D125T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 125A - 300mA | Под заказ | По запросу | |
| HDB3WLE1253D125W |
Производитель: HDB3WLE1253D125W
Поставщик: HDB3WLE1253D125W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 125A - 50mA | Под заказ | По запросу | |
| HDB3WLE1253D125Y |
Производитель: HDB3WLE1253D125Y
Поставщик: HDB3WLE1253D125Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 125A - 100mA | Под заказ | По запросу | |
| HDB3WLE1253D63 |
Производитель: HDB3WLE1253D63
Поставщик: HDB3WLE1253D63
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 63A | Под заказ | По запросу | |
| HDB3WLE1253D63Q |
Производитель: HDB3WLE1253D63Q
Поставщик: HDB3WLE1253D63Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 63A - 75mA | Под заказ | По запросу | |
| HDB3WLE1253D63T |
Производитель: HDB3WLE1253D63T
Поставщик: HDB3WLE1253D63T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 63A - 300mA | Под заказ | По запросу | |
| HDB3WLE1253D63W |
Производитель: HDB3WLE1253D63W
Поставщик: HDB3WLE1253D63W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 63A - 50mA | Под заказ | По запросу | |
| HDB3WLE1253D63Y |
Производитель: HDB3WLE1253D63Y
Поставщик: HDB3WLE1253D63Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 63A - 100mA | Под заказ | По запросу | |
| HDB3WLE1253D80 |
Производитель: HDB3WLE1253D80
Поставщик: HDB3WLE1253D80
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 80A | Под заказ | По запросу | |
| HDB3WLE1253D80Q |
Производитель: HDB3WLE1253D80Q
Поставщик: HDB3WLE1253D80Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 80A - 75mA | Под заказ | По запросу | |
| HDB3WLE1253D80T |
Производитель: HDB3WLE1253D80T
Поставщик: HDB3WLE1253D80T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 80A - 300mA | Под заказ | По запросу | |
| HDB3WLE1253D80W |
Производитель: HDB3WLE1253D80W
Поставщик: HDB3WLE1253D80W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 80A - 50mA | Под заказ | По запросу | |
| HDB3WLE1253D80Y |
Производитель: HDB3WLE1253D80Y
Поставщик: HDB3WLE1253D80Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P - D - 80A - 100mA | Под заказ | По запросу | |
| HDB3WLE1254C100 |
Производитель: HDB3WLE1254C100
Поставщик: HDB3WLE1254C100
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - C - 100A | Под заказ | По запросу | |
| HDB3WLE1254C125 |
Производитель: HDB3WLE1254C125
Поставщик: HDB3WLE1254C125
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - C - 125A | Под заказ | По запросу | |
| HDB3WLE1254C63 |
Производитель: HDB3WLE1254C63
Поставщик: HDB3WLE1254C63
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - C - 63A | Под заказ | По запросу | |
| HDB3WLE1254C80 |
Производитель: HDB3WLE1254C80
Поставщик: HDB3WLE1254C80
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - C - 80A | Под заказ | По запросу | |
| HDB3WLE1254D100 |
Производитель: HDB3WLE1254D100
Поставщик: HDB3WLE1254D100
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 100A | Под заказ | По запросу | |
| HDB3WLE1254D100Q |
Производитель: HDB3WLE1254D100Q
Поставщик: HDB3WLE1254D100Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 100A - 75mA | Под заказ | По запросу | |
| HDB3WLE1254D100T |
Производитель: HDB3WLE1254D100T
Поставщик: HDB3WLE1254D100T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 100A - 300mA | Под заказ | По запросу | |
| HDB3WLE1254D100W |
Производитель: HDB3WLE1254D100W
Поставщик: HDB3WLE1254D100W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 100A - 50mA | Под заказ | По запросу | |
| HDB3WLE1254D100Y |
Производитель: HDB3WLE1254D100Y
Поставщик: HDB3WLE1254D100Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 100A - 100mA | Под заказ | По запросу | |
| HDB3WLE1254D125 |
Производитель: HDB3WLE1254D125
Поставщик: HDB3WLE1254D125
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 125A | Под заказ | По запросу | |
| HDB3WLE1254D125Q |
Производитель: HDB3WLE1254D125Q
Поставщик: HDB3WLE1254D125Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 125A - 75mA | Под заказ | По запросу | |
| HDB3WLE1254D125T |
Производитель: HDB3WLE1254D125T
Поставщик: HDB3WLE1254D125T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 125A - 300mA | Под заказ | По запросу | |
| HDB3WLE1254D125W |
Производитель: HDB3WLE1254D125W
Поставщик: HDB3WLE1254D125W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 125A - 50mA | Под заказ | По запросу | |
| HDB3WLE1254D125Y |
Производитель: HDB3WLE1254D125Y
Поставщик: HDB3WLE1254D125Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 125A - 100mA | Под заказ | По запросу | |
| HDB3WLE1254D63 |
Производитель: HDB3WLE1254D63
Поставщик: HDB3WLE1254D63
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 63A | Под заказ | По запросу | |
| HDB3WLE1254D63Q |
Производитель: HDB3WLE1254D63Q
Поставщик: HDB3WLE1254D63Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 63A - 75mA | Под заказ | По запросу | |
| HDB3WLE1254D63T |
Производитель: HDB3WLE1254D63T
Поставщик: HDB3WLE1254D63T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 63A - 300mA | Под заказ | По запросу | |
| HDB3WLE1254D63W |
Производитель: HDB3WLE1254D63W
Поставщик: HDB3WLE1254D63W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 63A - 50mA | Под заказ | По запросу | |
| HDB3WLE1254D63Y |
Производитель: HDB3WLE1254D63Y
Поставщик: HDB3WLE1254D63Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 63A - 100mA | Под заказ | По запросу | |
| HDB3WLE1254D80 |
Производитель: HDB3WLE1254D80
Поставщик: HDB3WLE1254D80
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 80A | Под заказ | По запросу | |
| HDB3WLE1254D80Q |
Производитель: HDB3WLE1254D80Q
Поставщик: HDB3WLE1254D80Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 80A - 75mA | Под заказ | По запросу | |
| HDB3WLE1254D80T |
Производитель: HDB3WLE1254D80T
Поставщик: HDB3WLE1254D80T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 80A - 300mA | Под заказ | По запросу | |
| HDB3WLE1254D80W |
Производитель: HDB3WLE1254D80W
Поставщик: HDB3WLE1254D80W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 80A - 50mA | Под заказ | По запросу | |
| HDB3WLE1254D80Y |
Производитель: HDB3WLE1254D80Y
Поставщик: HDB3WLE1254D80Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 4P - D - 80A - 100mA | Под заказ | По запросу | |
| HDB3WLE1256C100 |
Производитель: HDB3WLE1256C100
Поставщик: HDB3WLE1256C100
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - C - 100A | Под заказ | По запросу | |
| HDB3WLE1256C125 |
Производитель: HDB3WLE1256C125
Поставщик: HDB3WLE1256C125
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - C - 125A | Под заказ | По запросу | |
| HDB3WLE1256C63 |
Производитель: HDB3WLE1256C63
Поставщик: HDB3WLE1256C63
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - C - 63A | Под заказ | По запросу | |
| HDB3WLE1256C80 |
Производитель: HDB3WLE1256C80
Поставщик: HDB3WLE1256C80
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - C - 80A | Под заказ | По запросу | |
| HDB3WLE1256D100 |
Производитель: HDB3WLE1256D100
Поставщик: HDB3WLE1256D100
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 100A | Под заказ | По запросу | |
| HDB3WLE1256D100Q |
Производитель: HDB3WLE1256D100Q
Поставщик: HDB3WLE1256D100Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 100A - 75mA | Под заказ | По запросу | |
| HDB3WLE1256D100T |
Производитель: HDB3WLE1256D100T
Поставщик: HDB3WLE1256D100T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 100A - 300mA | Под заказ | По запросу | |
| HDB3WLE1256D100W |
Производитель: HDB3WLE1256D100W
Поставщик: HDB3WLE1256D100W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 100A - 50mA | Под заказ | По запросу | |
| HDB3WLE1256D100Y |
Производитель: HDB3WLE1256D100Y
Поставщик: HDB3WLE1256D100Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 100A - 100mA | Под заказ | По запросу | |
| HDB3WLE1256D125 |
Производитель: HDB3WLE1256D125
Поставщик: HDB3WLE1256D125
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 125A | Под заказ | По запросу | |
| HDB3WLE1256D125Q |
Производитель: HDB3WLE1256D125Q
Поставщик: HDB3WLE1256D125Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 125A - 75mA | Под заказ | По запросу | |
| HDB3WLE1256D125T |
Производитель: HDB3WLE1256D125T
Поставщик: HDB3WLE1256D125T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 125A - 300mA | Под заказ | По запросу | |
| HDB3WLE1256D125W |
Производитель: HDB3WLE1256D125W
Поставщик: HDB3WLE1256D125W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 125A - 50mA | Под заказ | По запросу | |
| HDB3WLE1256D125Y |
Производитель: HDB3WLE1256D125Y
Поставщик: HDB3WLE1256D125Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 125A - 100mA | Под заказ | По запросу | |
| HDB3WLE1256D63 |
Производитель: HDB3WLE1256D63
Поставщик: HDB3WLE1256D63
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 63A | Под заказ | По запросу | |
| HDB3WLE1256D63Q |
Производитель: HDB3WLE1256D63Q
Поставщик: HDB3WLE1256D63Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 63A - 75mA | Под заказ | По запросу | |
| HDB3WLE1256D63T |
Производитель: HDB3WLE1256D63T
Поставщик: HDB3WLE1256D63T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 63A - 300mA | Под заказ | По запросу | |
| HDB3WLE1256D63W |
Производитель: HDB3WLE1256D63W
Поставщик: HDB3WLE1256D63W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 63A - 50mA | Под заказ | По запросу | |
| HDB3WLE1256D63Y |
Производитель: HDB3WLE1256D63Y
Поставщик: HDB3WLE1256D63Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 63A - 100mA | Под заказ | По запросу | |
| HDB3WLE1256D80 |
Производитель: HDB3WLE1256D80
Поставщик: HDB3WLE1256D80
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 80A | Под заказ | По запросу | |
| HDB3WLE1256D80Q |
Производитель: HDB3WLE1256D80Q
Поставщик: HDB3WLE1256D80Q
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 80A - 75mA | Под заказ | По запросу | |
| HDB3WLE1256D80T |
Производитель: HDB3WLE1256D80T
Поставщик: HDB3WLE1256D80T
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 80A - 300mA | Под заказ | По запросу | |
| HDB3WLE1256D80W |
Производитель: HDB3WLE1256D80W
Поставщик: HDB3WLE1256D80W
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 80A - 50mA | Под заказ | По запросу | |
| HDB3WLE1256D80Y |
Производитель: HDB3WLE1256D80Y
Поставщик: HDB3WLE1256D80Y
|
Residual Current Operated Circuit Breaker HDB3wLE-125 - 3P+N - D - 80A - 100mA | Под заказ | По запросу |
Характеристики
Товар и SKU
ATS_CURVE_CODE
- Curve code
- D | C
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N | 2P | 3P + N | 3P | 4P
ATS_RATED_CURRENT
- [In] rated current
- 63 A | 63.0 A | 80.0 A | 80 A | 100 A | 100.0 A | 125 A | 125.0 A
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA | 50.0 mA | 75.0 mA | 100.0 mA | 300.0 mA
Сравнение SKU
| SKU | Ambient air temperature for operation | Breaking capacity | Cable entry | Clamping connection capacity | Connections - terminals | Curve code | Depth | Device application |
|---|---|---|---|---|---|---|---|---|
| HDB3WLE1251C100 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251C125 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251C63 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251C80 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D100 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D100G | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D100Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D100T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D100W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D100Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D125 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D125G | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D125Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D125T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D125W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D125Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D63 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D63G | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D63Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D63T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D63W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D63Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D80 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D80G | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D80Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D80T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D80W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1251D80Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 66.0 mm | | Isolation | Control | |
| HDB3WLE1252C100 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1252C125 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1252C63 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1252C80 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D100 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D100G | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D100Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D100T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D100W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D100Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D125 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D125G | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D125Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D125T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D125W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D125Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D63 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D63G | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D63Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D63T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D63W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D63Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D80 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D80G | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D80Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D80T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D80W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1252D80Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253C100 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1253C125 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1253C63 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1253C80 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D100 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D100Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D100T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D100W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D100Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D125 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D125Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D125T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D125W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D125Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D63 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D63Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D63T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D63W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D63Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D80 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D80Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D80T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D80W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1253D80Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254C100 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1254C125 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1254C63 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1254C80 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D100 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D100Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D100T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D100W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D100Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D125 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D125Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D125T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D125W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D125Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D63 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D63Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D63T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D63W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D63Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D80 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D80Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D80T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D80W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1254D80Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256C100 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1256C125 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1256C63 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1256C80 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | C | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D100 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D100Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D100T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D100W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D100Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D125 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D125Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D125T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D125W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D125Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D63 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D63Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D63T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D63W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D63Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D80 | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D80Q | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D80T | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D80W | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
| HDB3WLE1256D80Y | -20…60 °C | | 10.0 kA | | Top | | <= 50 mm² | | Forked type tag connectors | | D | | 78 mm | | Isolation | Control | |
Все характеристики по каждому SKU
HDB3WLE1251C100
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251C125
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251C63
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251C80
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D100
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D100G
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D100Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D100T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D100W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D100Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D125
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D125G
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D125Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D125T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D125W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D125Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D63
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D63G
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D63Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D63T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D63W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D63Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D80
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D80G
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D80Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D80T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D80W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1251D80Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 66.0 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 112.1 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 1P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 54.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252C100
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252C125
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252C63
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252C80
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D100
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D100G
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D100Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D100T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D100W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D100Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D125
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D125G
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D125Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D125T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D125W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D125Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
Offer Sustainability
- Sustainable packaging
- No |
HDB3WLE1252D63
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D63G
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D63Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D63T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D63W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D63Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D80
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D80G
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D80Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D80T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D80W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1252D80Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 2P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 230 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 81.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253C100
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253C125
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253C63
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253C80
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D100
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D100Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D100T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D100W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D100Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D125
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D125Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D125T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D125W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D125Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D63
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D63Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D63T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D63W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D63Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D80
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D80Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D80T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D80W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1253D80Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254C100
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254C125
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254C63
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254C80
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D100
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D100Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D100T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D100W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D100Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D125
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D125Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D125T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D125W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D125Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D63
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D63Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D63T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D63W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D63Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D80
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D80Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D80T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D80W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1254D80Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 4P |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 135.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256C100
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256C125
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256C63
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256C80
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- C |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 8.5 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D100
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D100Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D100T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D100W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D100Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 100.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D125
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D125Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D125T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D125W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D125Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 125.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D63
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D63Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D63T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D63W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D63Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 63.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D80
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 30.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D80Q
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 75.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D80T
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 300.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D80W
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 50.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
HDB3WLE1256D80Y
ATS_AMBIANT_AIR_TEMPERATURE
- Ambient air temperature for operation
- -20…60 °C |
ATS_BREAKING_CAPACITY
- Breaking capacity
- 10.0 kA |
ATS_CERTIFICATIONS
- Product certifications
- CE |
ATS_CURVE_CODE
- Curve code
- D |
ATS_DEPTH
- Depth
- 78 mm |
ATS_DEVICE_APPLICATION
- Device application
- Isolation | Control |
ATS_HEIGHT
- Height
- 86.4 mm |
ATS_IP_PROTECTION
- IP degree of protection
- IP20 |
ATS_MOUNTING_SUPPORT
- Mounting support
- 35 mm DIN rail |
ATS_POLES_DESCRIPTION
- Poles description
- 3P + N |
ATS_PRODUCT_OR_COMPONENT_TYPE
- Product or component type
- Residual current breaker with overcurrent protection (RCBO) |
ATS_RATED_CURRENT
- [In] rated current
- 80.0 A |
ATS_RATED_INSULATION_VOLTAGE
- [Ui] rated insulation voltage
- 250 V between phase and neutral | 500 V between phases |
ATS_RATED_OPERATIONAL_VOLTAGE
- [Ue] rated operational voltage
- 400 V AC 50...60 Hz |
ATS_RESIDUAL_CURRENT
- Residual current
- 100.0 mA |
ATS_WIDTH
- Width
- 108.0 mm |
Complementary
- Cable entry
- Top |
- Clamping connection capacity
- <= 50 mm² |
- Connections - terminals
- Forked type tag connectors |
- Electrical durability
- 3000 cycles |
- Environmental characteristic
- High temperature: category 2 28 cycles conforming to IEC 60068-2 | Humidity resistant: category 2 28 cycles conforming to IEC 60068-2 |
- Magnetic tripping limit
- 12 x In |
- Mechanical durability
- 8500 cycles |
- Protection type
- Short-circuit protection | Overload protection | Earth-leakage protection | Residual current breaker with overcurrent protection (RCBO) |
- Provision for padlocking
- Handle padlockable in on and off position |
- Reset
- Manual reset earth leakage | Manual reset overcurrent |
- Suitability for isolation
- Yes |
- Tightening torque
- 3.5 N.m |
- Trip unit technology
- Thermal-magnetic |
- [Uimp] rated impulse withstand voltage
- 4.0 kV |
Environment
- Dielectric test voltage
- 2.0 kV 50...60 Hz 1 min |
- Pollution degree
- 2 |
- Shock resistance
- 30 gn (duration = 11.0 ms) for 3 shocks |
- Standards
- IEC 61009-1 |
Main
- Range of product
- HDB3wLE-125 |
Документы
Руководства, сертификаты и материалы производителя
Сертификаты
Руководства
Похожие товары и серии
УЗО и дифавтоматы
Еще из этой категории
-
-
-
-
-
-
-
HIMEL ProductsПод заказ Нет ценыАртикулы: HDB3LTH1C10R10, HDB3LTH1C10R100, HDB3LTH1C10R30 и еще 33 -
